Original Xhorse VVDI 2 Commander Key Programmer=VVDI options + BMW Multi Tool options +Porsche options+j2534(free)+ tango(free)+Remote control generation(free)…..more other function.
Software version: 1.2.5 (newest)
Firmware version: V2.2.5
Operating system: Windows XP/Windows 7
Update: Free online lifetime
VVDI2 Key Programmer functions:
1.Includes all VVDI functions, Tango function , remote control generation and chip identification is improved, and also the coil’s stability has been enhanced.
2.No need to connect VVDI2 with computer or other devices to identify chip or detect remote frequently.
3.VVDI2 Covers All the Functions of VVDI, VVDI 5th IMMO Adapter, BMW Multi Tool, CAS Plus, CAS4 Adapter, Tango, J2534
4. 5 in 1 programmer. No Need to buy other Authorization.
VVDI 2=VVDI PROGRAMMER SV30nbsp;+ BMW MULTI TOOL SK97+ BMW CAS PLUS SK108+ CAS 4 BMW SK97-B + 5th IMMO FOR VVDI SO146
VVDI 2 Overview
VVDI 2 Update Online Manual
VVDI 2 Key Programmer User Manual
Difference Among All the VVDI2 Key Programmers:
| Item Name&No | VVDI2 Full Version (SV86) |
VVDI Basic Version and VW Module Plus 5th IMMO Authorization (SV86-B) |
VVDI Basic Version Only (SV86-C) |
| Price | 2229.00USD | 1550.00USD | 465.00EUR |
| VW | √ | √ | × |
| BMW | √ | √ | × |
| Porsche | √ | × | × |
| 5th AUDI Authorization | √ | √ | +320USD (SV86-2) |
| BMW OBD Authorization | √ | +720USD (SV86-3) | +720USD (SV86-3) |
| BMW CAS4 + Authorization | √ | +260USD (SV86-4) | +260USD (SV86-4) |
*** Require firmware V2.2.5===== VAG V1.2.5 =====
1. Support copy 48 transponder(Menu->Key Learn->4th Immobilizer system – Copy 48 Transponder)
(1). Authorize copy 48 function require 1000 remote points, require an extra emulator, every success calculate will cost 100 remote points
(2). You can exchange it with “Transponder Programmer -> Menu -> Points System”
(3). Copy 48 fucntion can work on the car that which support read PIN and CS via OBDII. Ofcourse, known CS and PIN is supported
(4). Support clone key, support make new key, support add keyless GO keys, especially support lost all key. All do via OBDII, DON’T need read EEPROM with programmer
(5). Mainly use type: NEC24C32, NEC24C64, NEC24C64 colordisplay, A1, A3/TT/R8, Q3, New tiguan 5ND920873B, 5ND920883B etc
2. Add identification for new A6/Q7 J518(this type not support read via OBDII), avoid damage J518 when you read EEPROM via OBDII
3. Bugfix
===== BMW V1.2.5 =====
1. Bugfix
===== Porsche V1.2.5 =====
1. Bugfix
===== PSA V2.0.6 =====
1. Bugfix
===== Transponder Programmer V1.2.5 =====
1. Points System: You can exchange copy 48 function by yourself, require 1000 remote points
2. Special Transponder: Add DongFeng-Succe 1.5L immobox
3. Make Remote: Bugfix for Chevrolet Epica
4. Immobilizer data tool: Toyota Echo ECU 25040 bugfix
5. Immobilizer data tool: Add support SaicMotor Roewe 360 remote immobilizer
6. Bugfix
===== J2534 V1.2.5 =====
1. Bugfix
===== Online Upate Tool V1.2.5 =====
1. Bugfix
===== Quick Start V1.2.5 =====
1. Bugfix
Notes: about copy 48 function,require VAG 4th immo authorization.
Free download VVDI2 V1.2.5 Software
https://mega.nz/#!qspACLIB!rPVM8E7JXtd7KXpa81w3jOMtylPuTuPdcEuLd4TCPdI
1. 4th immobilizer support follow types:
(1) NEC24C32 Support add key and lost all key via OBDII
(2) NEC24C64 Support add key and lost all key via OBDII
(3) Motorola Support add key and lost all key via OBDII
(4) NEC95320 Support add key and lost all key via OBDII
(5) CDC32xx Support add key and lost all key via OBDII
(6) NEC35xx Support add key via OBDII, some cars with marelli support lost all key vaid OBDII
(7) Passat B6/CC Support add key and lost all key via OBDII
(8) A3/TT/R8 Support add key and lost all key via OBDII
(9) Q3 Support add key and lost all key via OBDII
(10) A4(RB4, RB8) Support add key and lost all key via OBDII
(11) A6/Q7 Support add key and lost all key via OBDII
(12) Touareg/Phaeton/A8/Cayenne support add key (some type support OBDII)
Attention 1: Lost all key via OBDII support keyless GO cars(UDS dashboard)
Attention 2: Copy 48 window released(Menu->Key Learn->4th Immobilizer system – Copy 48 Transponder). Copy 48 require authorize(1000 remote points), and require a 48 collector
Attention 3: In future, points will have more power function, save as more as you can
2. Bugfix
1. Bugfix
1. Bugfix
1. Bugfix
1. Fix bug for copy some HITAG2(46) transponder
2. Prepare remote: Add support for Chevrolet Epica
3. Immobilizer data tool: bugfix Skoda fabia 93C86
4. Bugfix
1. Bugfix
1. Bugfix
1. Add support for MED17/EDC17 dump tool, support clone ECU(Menu->Special Function->MED17/EDC17 dump tool)
2. Bugfix for write CDC32xx immo data
3. Show MAC and power class for some type Audi RB8 in immodata
4. Bugfix
1. Bugfix
1. Bugfix
1. Bugfix
1. Add support for copy remote
2. Bugfix for update remote database
3. Immobilizer data tool: bugfix Citroen Berling 2000 NEC
4. Immobilizer data tool: bugfix VW immobox 93C56 show ID error
5. Immobilizer data tool: bugfix Mitsubishi Colt 2004 9S12
6. Immobilizer data tool: bugfix Renault Clio III 2005 95160
1. Bugfix
VVDI 2 1.1.7 Update Feature: 2016-08-10
*** Require firmware V2.1.7
VAG V1.1.7
1. Bugfix for guided function
2. Bugfix for flash some FRF file
3. Bugfix for autodetect lavida cluster
4. Bugfix for write CDC32xx immo data
5. Bugfix
BMW V1.1.7
1. Add support for disable/enable EWS key in “File Key Maker”
2. Add supprot for E series coding
3. Some window is improved
4. Bugfix for show ISN when lost all key
5. Bugfix
Porsche V1.1.7
1. Bugfix
PSA V2.0.1
1. Bugfix
Transponder Programmer V1.1.7
1. Immobilizer data tool: bugfix Opel IMMO-1 68HC05
2. Immobilizer data tool: bugfix Renault Latitude 2010-
3. Immobilizer data tool: bugfix Hyundai Tucson 29F400
4. Make Remote: New database released, now support make remote under wireless mode
5. Bugfix
J2534 V1.1.7
1. Bugfix
Online Upate Tool V1.1.7
1. Bugfix
Quick Start V1.1.7
1. Bugfix
VVDI2 V1.1.6 Installer Software Free Download
VVDI 2 Updated to V1.1.5(June 6th, 2016)
V1.1.5 Software Download
*** Require firmware V2.1.5
VAG V1.1.5
1. Bugfix
BMW V1.1.5
1. Bugfix
Porsche V1.1.5
1. Bugfix
Transponder Programmer V1.1.5
1. Bugfix
J2534 V1.1.5
1. Bugfix
Online Upate ToolV1.1.5
1. Bugfix
Quick Start V1.1.5
1. Bugfix
VVDI2 V1.1.4 (2016-06-03)
*** Require firmware V2.1.4
VVDI2 – Transponder Programmer become part of VVDI Key Tool
While VVDI Key Tool run on VVDI2, it support the old function list in VVDI2 – Transponder Programmer, new function don’t support
While VVDI Key Tool run on new VVDI Key Tool device, it support all function: Transponder programmer, Special transponder, Immobilizer data tool, NXP renew, Copy transponder, Prepare Remote, Verify Key etc
VAG V1.1.4
1. Bugfix for unit flash programmer
2. Guided function: Engine, ABS, Central Electric, Convenience, Instruments, Add.heating, Handbrake, Immobilizer, Airbag, Xenon, DPF etc
3. Bugfix
BMW V1.1.4
1. Bugfix
Porsche V1.0.6
1. Bugfix
J2534 V1.0.6
1. Bugfix
VVDI Key Tool V1.0.0
1. Support unlock toyota smart key: 40bit/80bit (Function list in Other Key Tool)
2. Special transponder: bugfix ZhongHua H230
3. Immobilizer data tool: bugfix Toyota Camry ECU 93C56
4. Immobilizer data tool: bugfix Toyota passo 93C66 4C
5. Immobilizer data tool: bugfix Nissan Qashqai 2010 9S12
6. Immobilizer data tool: bugfix Iveco Daily 93C56
7. Immobilizer data tool: bugfix Toyota Yaris 2001 25020
8. Immobilizer data tool: bugfix Renault laguna III 9S12
9. Bugfix
Online Upate Tool V1.0.9
1. Bugfix
Quick Start V1.0.6
1. Bugfix
VVDI 2 V1.1.3 Update Feature:
1. Add decode 95160 EEPROM for touareg 2008
2. Fixbug for read PIN and CS in med17.5 ECU
3. Fixbug for passat B6 find 7th bytes CS
4. Added guided functions: ECU/ABS following: (other modules will add soon)(Menu->Diagnostic->Guided Functions)
Engine:
Activation of cruise control
Throttle adaptation – Otto engines with Drive-By-Wire
Turning on Pre-Fuel pump (eg. for bleeding)
Injectors checking 3.0/2.7 TDI
Pump-jet checking 1.9/2.0 TDI
Adaptation of turbocharger in 2.7/3.0TDi engines
Adaptation of flap motors in 3.0/2.7 TDi engines
Testing Mass air flow meter G70 in TDI engines
Chiptuning test
Adaptation of G336 sensor (intake manifold’s flaps) in 2.0TFSi BPY/AXX
Adaptation of Turbocharger sensors used in CBAB CBAC 2.0TDi CR engines
Adaptation of EGR valve in Gasoline engines
Adaptation of start quantity in TDI VP Engines
Start/Stop deactivation in MQB cars (Golf 7, Octavia 3 etc)
Calibration of G85 sensor
FillingUp Brake system (MK60/70 – Golf V / Passat / Altea / Leon)
Enable / Disable \”SystemTest\” for ABS/ESP
Calibration of ESP acceleration sensor G200
Calibration of ESP pressure sensor G201
Calibration of ESP acceleration sensor G251
LHD/RHD ESP Coding
Recoding ABS/ESP variant (USA/EU)
ESP sensor calibration G200,G202,G251 in cars newer than 06.2007
Adaptation ESP ECU for DSG Gearbox in Audi A3 8P MJ2006
Total deactivation/activation of ESP MK60EC1
1. Add support for lost all key with newest firmware: 9395656, 9395657, 9389115, 9389116
2. Improvement file make key window, show VIN, key cutting code, remote frequency, ISN etc
3. Add disable/enable key for CAS1/2/3/3+/4/4+ in file make key
4. Fixbug for EWS4 KM
5. Fixbug for change KM 5M48H with error checksum
6. Bugfix
1. Bugfix
1. Add new window for Hitag3, support read/write page with password
2. Immo data tool bugfix: Renault Trucks Magnum 2000 – 93C46
3. Immo data tool bugfix: Daihastu Sirion -2003 93C66(4C)
4. Immo data tool bugfix: Euro Gilear Fuoco ST10F269
5. Immo data tool bugfix: Ducati Monster 696
6. Immo data tool bugfix: Renault Laguna II 95160
7. Immo data tool bugfix: Mercedes benz Vito 68HC
8. Immo data tool add new for toyota 93C66
9. Bugfix
VVDI 2 VVDI 2 V1.1.2 Update Feature:
Free download VVDI 2 V1.1.2 software
https://mega.nz/#!sktk0CTD!yLQWrvwjc-wyzoyT4LZjGjYd_MKO-VJh5qeG9b6ABe0
===== VAG V1.1.2 =====
1. Fixbug for prepare dealer key in audi RB4 crypto type
2. Fixbug for change KM in A6 (CAN protocol)
3. Immprove autodetect 4th immobilizer, support more cars
4. Bugfix
===== BMW V1.1.2 =====
1. Fixbug for change KM in CAS2
2. Fixbug for read key info from CAS2
3. Bugfix
===== Porsche V1.0.4 =====
1. Bugfix
===== Transponder Programmer V1.1.2 =====
1. Other Key Tool: make dealer key with 7 bytes CS / Find 7th byte CS : add no manufacture type
2. Immobilizer Data Tool add the following car support:
Subaru XV 2012
Sabura Forester 1998
Volvo XC70 2008
Volvo V70 2008
Dodge Ram 2008 uPD70F
Dodge Charger 2008 uPD70F
Dodge Sprinter 2006
Jeep Grand Cherokee 2008 uPD70F
Jeep Laredo 2008 uPD70
Saic MG3
Kia Cee’d 2012 STM8
Kia Soul 2008
Chevrolet Silverado 2011
Chevrolet Camaro 2015
Chevrolet Aveo 2012
Chevrolet Captiva 2011
Chevrolet Matiz 2006
Chevrolet Camaro 2015
Nissan Teana 2012
Mitsubishi Montero 2008
Mitsubishi Montero 2000
Mitsubishi Space Wagon 1999
Mitsubishi Pajero 2000
Mitsubishi Pajero Sport 2000
Mitsubishi Fuso Canter 2009
Mitsubishi Mirage 2010
Tata Safari 1999
Iveco Stralis 2008
Isuzu KB250D
Toyota smart systems certification ECU
Toyota Previa Immobox 2003
Toyota Yaris 2004
Mazda Tribute 2008
Kawasaki Denso 21175
Kawasaki Denso 21175 0811
VAZ Priora 2013
Piaggio Vespa LX125
Fiat Ducato 2012
Fiat Burstner Viseo 2011
Peugeot Boxer 2012
Pergeot Manager 2013
Renault Latitude 2010
Renault Safrane 2010
Renault Samsung SM5 2010
VW Golf 5 Viesteon 2008
VW Beetle 2008
Ford focus 2012
Ford Escapte 2012
VVDI2 VVDI II V1.1.1 Software Function
===== VAG V1.1.1 =====
- Fix bug for Audi A4 RB8 cyrpto make dealer key
- Fix bug for read Audi A6 J518
- Add START/STOP data for passat B6/CC with 48 transponder, require 7 bytes CS
- Add option for “Help VVDI2 improve 4th immobilizer cluster autodetect”. See detail in dianostic parameters
- Bugfix
===== BMW V1.1.1 =====
- Add repair CAS PLUG method to read EWS. See detail in BMW user manual v1.1
- Fix bug for BMW EWS1/2/3/4 make dealer key
- Fix bug for some F-Series cluster change KM
- Bugfix
===== Porsche V1.0.3 =====
- Bugfix
===== Transponder Programmer V1.1.1 =====
- Fix bug for BMW EWS1/2/3/4 make dealer key
- Bugfix
===== Online Upate Tool V1.0.8 =====
- Bugfix
VVDI2 VVDI II V1.1.0 Software Function
- Fix bug for read BCM2 bug with BDM programmer
- Fix bug for change KM with old A6 (CAN protocol)
- Bugfix
===== BMW V1.1.0 =====
- Bugfix
===== Porsche V1.0.2 =====
- Fix bug for porsche key learn
===== Transponder Programmer V1.1.0 =====
- Add auto antenna gain, no more set manually
- Bugfix
VVDI2 VVDI II V1.0.8 Software Function
- Fix bug for key learn in touareg(KWP2000), bentley(KWP2000)
2. Add support for BFM remote control (car with BFM system, such as polo, jetta etc)
3. Add support for flash programming _E type FRF file
4. Add support for get PIN and CS from cayenne ECU (4th immobilizer, EEPROM 95128)
5. Bugfix
BMW V1.0.8
- Fix bug for file change km (CAS1/CAS2/CAS3)
- Fix bug for BWM KWP protocol
- Language fix
Transponder Programmer V1.0.8
- Enhance programmer stability
- Fix bug for some Koleos 9S12 can’t detect key position
- Bugfix
How to update VVDI to VVDI 2?
- You Need to send whole package of VVDI to us, and pay 519USD for update, not including shipping cost. (SV86-1)
- If you don’t send VVDI package back, you need to pay for accessory cost.
FAQ:
Q: Can i use VVDI 2 or VVDI key program to add BMW CAS4+ keys? Do you have instruction for how to do that?
A: Yes. Please see the video guide in obd365 webpage.
Q: The function mentioned(ecu programming, key programming) for audi, vw, porsche, bmw, are they all for offline programming? Or do i need purchase online oem subscription to do that after purchase the vvdi2?
A: This machine support offline and online programming. offline and online we means with internet and without internet. Do not mean you can use original BMW factory account to connect BMW factory server to do programming.
Q: Hi I am wondering what is better? Xhorse vvdi2 or tm100? The vvdi needs to solder contacts in the ews. How bout the TM100?
A: 1) Quality
VVDI 2 is the genuine version made by xhorse company, quality is better than TM100.
2) Function
VVDI has special key model, for its function, it has the same way to programming keys as TM100, from this point, VVDI 2 cover the function for TM100. Besides, VVDI 2 also ahs BMW VAG series, and the function for FVDI. All these function TM100 does not support.
3) VVDI does not support EWS, VVDI 2 and VVDI PRO, TM100 can support EWS. If you use CAS PLUS adapter with VVDI2, SOMETIMES no need desolder chips.
Q: I do have BMW X5 from 2013+ , it’s F15 with CAS4+ I guess and 5M48H, it has all keys lost. What equipment I should buy from you to make a new key.
A: 1) For 5M48H, you need to use XPROG or VVDI pro to read the date
2) Use BMW MULTI TOOL or VVDI 2 do CAS4+, and use the data you read out to generate the key data to match programming and simultaneous car
For second steps. If you choose BMW MULTI TOOL, you still need to buy the CAS4 adapter. If you choose VVDI2, then no need to buy others.
Q: I want to open component security function. what should i do?
A: For this function. If you want to use, you need to open pin,mac reading,CS authorization then can use. If you have bought the condor key cutting machine. Then this authorization is free to open. Please give us your name/country/Email VVDI SN/ VVDI2 SN / CONDOR SN. If you do not bought CONDOR key cutting machine, then cannot open this authorization.
Q: Hello. I purchased this product and it says at the top… re synchronization in 23 days.. How do you re synchronization the device…Thank you
A: This is normal. Once the day become 1, you just need to connect interent. Then it will be back to 30 days again. This is setted by Xhorse company to avoid others crack their software.
