How to use CGDI Prog BMW to Program F30 FEM Key

Here’s the little guide on programming key on a BMW F30 FEM system with CGDI Prog BMW MSV80 key programmer.

Device required:

CGDI Prog BMW key programmer

BMW FEM/BDC Test Platform for BMW  F20 F30 F35 X5 X6 I3

Preparation:

Disassemble the FEM/BDC module from vehicle

Procedure:

Connect BMW FEM/BDC test platform with CGDI Prog  and FEM/BDC module

Open CGDI Prog BMW software

Select FEM/BDC Key Match

The current FEM BDC needs to update the ECU program before performing key matching. Please ensure that the car battery has enough power supply. Please do not disconnect cable connection during programming procedure.

Please remove the FEM BDC and then use the programmer to read and save the data from the
95xxx EEPROM chip on the FEM/BDC computer board, then click “Next”

Please read the original car EEPROM data

Read eeprom data with programmer, i.e Orange 5 eeprom programmer

and save data

User the programmer to write the calculated new data to the 95xxx eeprom chip, then put the FEM BDC back to the car
click Next

Click OK to write M95128

User the programmer to write the calcutaed new data to the 95xxx eeprom chip, then put the FEM BDC back to the car
click Next

Power on BMW FEM BDC test platform

The yellow indicator will flash

Coding is being backed up

The ECU is being programmed

and verify flashing

Program BMW F30 FEM key success
