Condor XC-Mini Key Cutter Series KM03 vs. KM02

This is for your information. It’s different between Condor XC-Mini KM02xx and KM03xx series

What is the difference between KM02xx and KM03xx series ?

The difference is:
motherboard, driver board, touch screen and add a fan near power.
KM03xx supports Bluetooth function.

Btw, you can activate Bluetooth on Laptop/Tablet or Smartphone and press the “search for machine” button in Instacode and it will pair with Condor Mini.

How do you know your machine is KM02 or KM03?

Mate,turn on the machine you will find machine SN and software version in main-interface.


Where to get KM03 with Bluetooth?

Here you go.

Condor Mini KM03 test report:

Today tried to cut HU55P, cutter started to the other direction and cut into the jaw

I cut some HU64 and never had a problem with it.

100% hu64 is ok with condor xc007 and condor mini km03 tested by me many times…

I used it to cut HU100. Worked like a charm!!!

HU66, HU49, HU83 cutting OK.

Recently got the Condor Mini.

Seems good. However if the dust cover could have been designed a bit away from key it would’ve been nice.

I haven’t no any problems with Condor XC-Mini

cut keys blade HU64-3 without any problems

Just got a new km03 from So very new to this. Been very successful up till now. Tried to decode a Renault megane emergency key Card type. Renault-megane-2003- Condor checks the clamp position ok then goes looking for the tip of the key but misses the tip with the prob going down the middle of the cut for 5mm then backs off as it thinks no key is in the clamp. Is it operator error or a bug. Look like the probe is not low enough to bump into the key tip. Other than this I’m very happy.

Condor KM02 feedback:

I have machine with SN starting with KM02.

To cut keys HU92 BMW need to be in 1.00MM, when you select HU92 the device will ask you to chose between Land ravor and BMW, Land Rover came with 1.00mm and BMW with 1.25mm, if you try to cut with 1.25mm the key will not turn.

I have proved with 4 different machines and 3 different cars.
