2006 Nissan Altima: How to Cut keys and Program remotes

This is how to decode & cut a key and program or add a new key to Nissan Altima year 2006.



If you have all remotes available:



Here, you must have all remotes on hand when performing this procedure. Any remotes not used during this procedure will become inactive.

  1. Close and lock all doors with the driver’s side power lock switch located on drivers door panel.
  2. Insert key into ignition (DON’T TURN) and remove it from the ignition key cylinder at least 6 times within 10 seconds (this will need to be done at approximately one second intervals). You may need to insert and remove the key up to 10 or 12 times until your hazard lamps flash. PLEASE NOTE: Withdraw key completely from ignition cylinder each time. If this procedure is performed too fast or too slow the system will not enter programming mode.
  3. Insert key into ignition and turn to the ACC position.
  4. Within 5 seconds, push the LOCK button on the keyless remote. Your hazard lamps will flash. PLEASE NOTE: Do not press the button on the remote more than one time or the programming will not be successful.
  5. If there are any remaining remotes (including working ones), Unlock then Lock all doors using the switch on drivers door panel. Within 5 seconds of locking and unlocking doors press LOCK button on the next remote. Your hazard lamps will flash. Repeat this step for each remote (including any working remotes).
  6. When all remotes have been programmed turn the key to the OFF position, remove keys from the ignition, unlock doors using the driver’s side power lock/unlock switch and open the driver side door. Test all remotes.



If you have a decent key only or lose all keys:

You need:

a Nissan NSPC001 pin code reader

a decent auto programming tool for the car: Nissan Consult 3 or Consult 3 plus

a security immobilizer card used to make keys to Nissan

a good automatic key cutter, such as SEC-E9 key cutting machine

and good new keys/remotes to add

The steps:

read pin – program key – decode and cut keys

in detail…

Step 1: NSPC001 reads pin codes



Connect the code reader into the OBD diagnostic socket

Read the 5-digit BCM code and transfer it to 4-digit pin code

Write down the pin code

Disconnect the pin code reader

Step 2: Nissan Consult 3 plus adds new keys

Connect Consult III plus to the computer and the vehicle

Connection method: via the USB cable or Bluetooth

Insert key into the key hole, turn ignition ON with engine OFF

Start Consult-III plus software

Click on “Connect” button on VIMI selection screen to connect with VI


			2006 Nissan Altima: How to Cut keys and Program remotes

the computer and vehicle establish good communication

then Consult3 plus software will display VIN info

Choose Nissan model and year, and confirm vehicle information


			2006 Nissan Altima: How to Cut keys and Program remotes

Wait until the Nissan Consult module to access all control modules, Engine, BCM, Transmission, Airbag etc.

The car dashboard will illuminate and the indicator lights on Consult 3 will flash


			2006 Nissan Altima: How to Cut keys and Program remotes

Diagnostic: Direct Diagnostic Mode program

Tick Key programming icon (NATS SELECT DIAG MODE) on the left menu, plug the security card and press START

(There are two options under NATS SELECT DIAG MODE. Select C/U INITIALIZATION.


			2006 Nissan Altima: How to Cut keys and Program remotes

Push START BUTTON after enter password

Manually enter the pin code

Initialization completed

Follow the guide in the sw to finish key programming

Step 3: SEC-E9 machine decodes and cuts Nissan keys

First decoding…then cutting….

SEC-E9 key cutting machine Nissan car list:

Car Brand Model Year IC Card
Nissan Juke 2010-0 9022
Nissan X-Trail 2007-0 6132
Nissan X-Trail 2007-0 6133
Nissan Versa 2007-0 6135
Nissan Versa 2007-0 6136
Nissan TidaLatio 2004-0 6137
Nissan Tida 2004-2012 6138
Nissan Skyline 1999-2006 6139
Nissan Sentra 2007-2009 6140
Nissan Sentra 2007-2009 6141
Nissan Rogue 2007-0 6142
Nissan Rogue 2007-0 6143
Nissan Qashqai 2007-0 6144
Nissan Qashqai 2007-0 6145
Nissan Pixo 2008-0 6146
Nissan Patrol 2007-0 6147
Nissan Pathfinder 2005-0 6148
Nissan Note 2006-0 6149
Nissan Note 2006-0 6150
Nissan Navara 2005-0 6151
Nissan Navara 2005-0 6152
Nissan Murano 2009-0 6153
Nissan Murano 2009-0 6154
Nissan Micra 2007-0 6155
Nissan Micra 2007-0 6156
Nissan Maxima 2007-0 6157
Nissan March 2003-2007 6158
Nissan March 2003-2007 6159
Nissan GTR 2007-0 6160
Nissan Elgrand 1997-2002 6161
Nissan Elgrand 2002-2010 6162
Nissan Cube 2002-2008 6163
Nissan Cube 2009-0 6164
Nissan Cabstar 2000-0 6165
Nissan Atlas Truck 2007-0 6166
Nissan Armada 2008-0 6167
Nissan Armada 2008-0 6168
Nissan 140Y 1973-1978 4770
Nissan 140Y 1973-1978 4771
Nissan 140Y 1978-1982 4772
Nissan 140Y 1978-1982 4773
Nissan 160J 1978-1982 4774
Nissan 160J 1978-1982 4775
Nissan 180B 1971-1976 4776
Nissan 180B 1971-1976 4777
Nissan 180SX 1989-1994 4778
Nissan 180SX 1995-1999 4779
Nissan 200B 1976-1980 4780
Nissan 200B 1976-1980 4781
Nissan 200SX 1984-1988 4782
Nissan 200SX 1995-1998 4783
Nissan 200SX (North America) 1984-1988 4784
Nissan 200SX (North America) 1995-1998 4785
Nissan 200ZR 1983-1989 4786
Nissan 210 1978-1982 4787
Nissan 210 1978-1982 4788
Nissan 240C 1975-1979 4789
Nissan 240C 1975-1979 4790
Nissan 240C 1979-1984 4791
Nissan 240C 1979-1984 4792
Nissan 240K 1977-1981 4793
Nissan 240K 1977-1981 4794
Nissan 240SX 1989-1994 4795
Nissan 240SX 1995-1998 4796
Nissan 240SX (North America) 1989-1994 4797
Nissan 240SX (North America) 1995-1998 4798
Nissan 240Z 1970-1976 4799
Nissan 240Z 1970-1976 4800
Nissan 260C 1975-1979 4801
Nissan 260C 1975-1979 4802
Nissan 260C 1979-1984 4803
Nissan 260C 1979-1984 4804
Nissan 260Z 1970-1976 4805
Nissan 260Z 1970-1976 4806
Nissan 280C 1975-1979 4807
Nissan 280C 1975-1979 4808
Nissan 280C 1979-1984 4809
Nissan 280C 1979-1984 4810
Nissan 280Z 1976-1978 4811
Nissan 280Z 1976-1978 4812
Nissan 280ZX 1979-1983 4813
Nissan 280ZX 1984-1996 4814
Nissan 300C 1983-1987 4815
Nissan 300ZX 1979-1983 4816
Nissan 300ZX 1983-1989 4817
Nissan 300ZX 1990-1996 4818
Nissan 300ZX 1997-1999 4819
Nissan 310 1979-1983 4820
Nissan 310 1979-1983 4821
Nissan 350Z 2003-0 4822
Nissan 510 1970-1973 4823
Nissan 510 1970-1973 4824
Nissan 510 1978-1982 4825
Nissan 510 1978-1982 4826
Nissan 610 1971-1976 4827
Nissan 610 1971-1976 4828
Nissan 620 1970-1979 4829
Nissan 710 1973-1977 4830
Nissan 710 1973-1977 4831
Nissan 720 1980-1982 4832
Nissan 720 1983-1986 4833
Nissan 810 1976-1980 4834
Nissan 810 1976-1980 4835
Nissan 810 1980-1982 4836
Nissan 810 1980-1982 4837
Nissan 810 1982-1984 4838
Nissan 810 1999-2003 4839
Nissan AD Resort 0-0 4840
Nissan AD Wagon 0-0 4841
Nissan Almera 2000-2004 4842
Nissan Almera Tino 2000-2006 4843
Nissan Altima 1992-1997 4844
Nissan Altima 1998-2000 4845
Nissan Altima 2000-2004 4846
Nissan Altima 2005-0 4847
Nissan Armada 2004-0 4848
Nissan Auster 1986-1989 4849
Nissan Auster 1989-1992 4850
Nissan Axxess 1990-1995 4851
Nissan B110 1970-1973 4852
Nissan B110 1970-1973 4853
Nissan B210 1973-1978 4854
Nissan B210 1973-1978 4855
Nissan Bluebird 1971-1976 4856
Nissan Bluebird 1971-1976 4857
Nissan Bluebird 1976-1980 4858
Nissan Bluebird 1976-1980 4859
Nissan Bluebird 1980-1982 4860
Nissan Bluebird 1980-1982 4861
Nissan Bluebird 1982-1984 4862
Nissan Bluebird 1985-1988 4863
Nissan Bluebird 1989-1992 4864
Nissan Bluebird 1992-1997 4865
Nissan Bolero 1997-0 4866
Nissan Cabstar 0-1982 4867
Nissan Cabstar 0-1982 4868
Nissan Cabstar Truck 0-1982 4869
Nissan Cabstar Truck 0-1982 4870
Nissan Caravan 0-0 4871
Nissan Caravan 0-0 4872
Nissan Caravan 0-0 4873
Nissan Caravan 0-0 4874
Nissan Cedric 1975-1979 4875
Nissan Cedric 1975-1979 4876
Nissan Cedric 1979-1984 4877
Nissan Cedric 1979-1984 4878
Nissan Cedric 1983-1987 4879
Nissan Cefiro 1990-1993 4880
Nissan Cefiro 1995-1999 4881
Nissan Cherry 0-0 4882
Nissan Cherry Europe 0-0 4883
Nissan Cima 1997-2000 4884
Nissan Cube 1998-2001 4885
Nissan EXA 1987-1990 4886
Nissan F10 1976-1978 4887
Nissan F10 1976-1978 4888
Nissan Fairlady Z 1970-1976 4889
Nissan Fairlady Z 1970-1976 4890
Nissan Fairlady Z 1976-1978 4891
Nissan Fairlady Z 1976-1978 4892
Nissan Fairlady Z 1979-1983 4893
Nissan Florida 1989-1991 4894
Nissan Frontier 1998-2004 4895
Nissan Frontier 2004-0 4896
Nissan Gazelle 1975-1979 4897
Nissan Gazelle 1975-1979 4898
Nissan Gazelle 1980-1983 4899
Nissan Gazelle 1980-1983 4900
Nissan Gazelle 1984-1988 4901
Nissan Gazelle 1989-1994 4902
Nissan Gazelle 1995-1999 4903
Nissan Gloria 1975-1979 4904
Nissan Gloria 1975-1979 4905
Nissan Gloria 1979-1984 4906
Nissan Gloria 1979-1984 4907
Nissan Gloria 1983-1987 4908
Nissan Hardbody 1985-1997 4909
Nissan Hardbody 1997-2000 4910
Nissan Homy 0-0 4911
Nissan Homy 0-0 4912
Nissan Homy 0-0 4913
Nissan King Cab 1985-1997 4914
Nissan King Cab 1997-2000 4915
Nissan Langley 1976-1978 4916
Nissan Langley 1976-1978 4917
Nissan Langley 1979-1983 4918
Nissan Langley 1979-1983 4919
Nissan Langley 1983-1986 4920
Nissan Langley 1987-1991 4921
Nissan Largo 1993-1994 4922
Nissan Largo 1996-2002 4923
Nissan Laurel 1983-1986 4924
Nissan Laurel Spirit 1983-1986 4925
Nissan Leopard Coupe 1984-1993 4926
Nissan Lucino 1995-1998 4927
Nissan March 1983-1992 4928
Nissan March 1992-1999 4929
Nissan March 2000-2003 4930
Nissan Maxima 1980-1982 4931
Nissan Maxima 1980-1982 4932
Nissan Maxima 1982-1984 4933
Nissan Maxima 1985-1988 4934
Nissan Maxima 1989-1992 4935
Nissan Maxima 1993-1995 4936
Nissan Maxima 1995-1999 4937
Nissan Maxima 1999-2000 4938
Nissan Maxima 2000-2003 4939
Nissan Maxima 2004-0 4940
Nissan Maxima (North America) 1980-1982 4941
Nissan Maxima (North America) 1980-1982 4942
Nissan Maxima (North America) 1982-1984 4943
Nissan Maxima (North America) 1985-1988 4944
Nissan Maxima (North America) 1989-1992 4945
Nissan Maxima (North America) 1993-1995 4946
Nissan Maxima (North America) 1995-1999 4947
Nissan Maxima (North America) 1999-2000 4948
Nissan Maxima (North America) 2000-2003 4949
Nissan Maxima (North America) 2004-0 4950
Nissan Micra 2000-2003 4951
Nissan Micra 2003-0 4952
Nissan Micra Van 2000-2003 4953
Nissan Micra Van 2003-0 4954
Nissan Mistral 1992-1995 4955
Nissan Mistral 1995-1996 4956
Nissan Mistral 1997-1998 4957
Nissan Multi 1986-1990 4958
Nissan Murano 2003-2005 4959
Nissan Murano 2005-0 4960
Nissan Navara 1985-1991 4961
Nissan Navara 1992-1997 4962
Nissan Navara 1997-2002 4963
Nissan Navara 2002-2003 4964
Nissan Navara 2003-0 4965
Nissan Nomad 1986-1989 4966
Nissan NX 1991-1993 4967
Nissan NX (North America) 1991-1993 4968
Nissan Pathfinder 1987-1995 4969
Nissan Pathfinder 1996-1999 4970
Nissan Pathfinder 2000-0 4971
Nissan Patrol 1981-1997 4972
Nissan Patrol 1997-1999 4973
Nissan Patrol 2000-2003 4974
Nissan Patrol 2004-0 4975
Nissan Pickup 1974-1980 4976
Nissan Pickup 1982-1986 4977
Nissan Pickup 1986-1997 4978
Nissan Pickup 1998-2003 4979
Nissan Pickup (North American) 1974-1980 4980
Nissan Pickup (North American) 1982-1986 4981
Nissan Pickup (North American) 1986-1997 4982
Nissan Pickup (North American) 1998-2003 4983
Nissan Pickup 620 1970-1979 4984
Nissan Pickup 720 1980-1982 4985
Nissan Pickup 720 1983-1986 4986
Nissan Pickup Roadstar 1978-1984 4987
Nissan Pickup Roadstar 1978-1984 4988
Nissan Pintara 1986-1989 4989
Nissan Pintara 1989-1991 4990
Nissan Pintara 1992-1999 4991
Nissan Prairie 1982-1990 4992
Nissan Prairie 1990-1995 4993
Nissan President 1990-1996 4994
Nissan President 1997-2001 4995
Nissan Primera 1990-1994 4996
Nissan Primera 1995-1996 4997
Nissan Primera 1997-1998 4998
Nissan Primera 1998-2000 4999
Nissan Primera 2000-2002 5000
Nissan Primera 2003-0 5001
Nissan Pulsar 1983-1986 5002
Nissan Pulsar 1987-1990 5003
Nissan Pulsar (North America) 1983-1986 5004
Nissan Pulsar (North America) 1987-1990 5005
Nissan Pulsar LX 2005-0 5006
Nissan Pulsar NX 1987-1990 5007
Nissan Quest 1993-1995 5008
Nissan Quest 1996-2002 5009
Nissan Quest 2004-0 5010
Nissan Roadstar 1978-1984 5011
Nissan Roadstar 1978-1984 5012
Nissan Rumba 1998-0 5013
Nissan Safari 1997-2000 5014
Nissan Sakura 1980-1983 5015
Nissan Sakura 1980-1983 5016
Nissan Samurai 1980-1983 5017
Nissan Samurai 1980-1983 5018
Nissan S-Cargo 0-0 5019
Nissan Sentra 1982-1986 5020
Nissan Sentra 1987-1990 5021
Nissan Sentra 1991-1994 5022
Nissan Sentra 1995-1999 5023
Nissan Sentra 2000-2003 5024
Nissan Sentra 2004-0 5025
Nissan Sentra (North America) 1982-1986 5026
Nissan Sentra (North America) 1987-1990 5027
Nissan Sentra (North America) 1991-1994 5028
Nissan Sentra (North America) 1995-1999 5029
Nissan Sentra (North America) 2000-2003 5030
Nissan Sentra (North America) 2004-0 5031
Nissan Sentra (Sedan & Hatch) 1987-1991 5032
Nissan Serena 1993-1994 5033
Nissan Serena 1996-0 5034
Nissan Silvia 1975-1979 5035
Nissan Silvia 1975-1979 5036
Nissan Silvia 1980-1983 5037
Nissan Silvia 1980-1983 5038
Nissan Silvia 1984-1988 5039
Nissan Silvia 1989-1994 5040
Nissan Silvia 1995-1999 5041
Nissan Skyline 1977-1981 5042
Nissan Skyline 1977-1981 5043
Nissan Skyline 1982-1986 5044
Nissan Skyline 1986-1991 5045
Nissan Sportstar 1978-1984 5046
Nissan Sportstar 1978-1984 5047
Nissan Stanza 1982-1986 5048
Nissan Stanza 1987-1989 5049
Nissan Stanza 1990-1992 5050
Nissan Stanza (North America) 1982-1986 5051
Nissan Stanza (North America) 1987-1989 5052
Nissan Stanza (North America) 1990-1992 5053
Nissan Stanza Wagon (North America) 1986-1990 5054
Nissan Sunny 1978-1984 5055
Nissan Sunny 1978-1984 5056
Nissan Sunny Pickup 1978-1984 5057
Nissan Sunny Pickup 1978-1984 5058
Nissan Terrano 1992-1995 5059
Nissan Terrano 1995-1996 5060
Nissan Terrano 1997-1998 5061
Nissan Terrano 1998-1999 5062
Nissan Terrano 2000-2001 5063
Nissan Terrano 2002-2003 5064
Nissan Terrano 2004-0 5065
Nissan Terrano II 1992-1995 5066
Nissan Terrano II 1995-1996 5067
Nissan Terrano II 1997-1998 5068
Nissan Terrano II 1998-1999 5069
Nissan Terrano II 2000-2001 5070
Nissan Terrano II 2002-2003 5071
Nissan Terrano II 2004-0 5072
Nissan Tino 2000-2004 5073
Nissan Titan 2004-0 5074
Nissan Trade Europe 0-0 5075
Nissan Tsubame 0-0 5076
Nissan Tsuru 1986-1990 5077
Nissan Tsuru II 1986-1990 5078
Nissan Urvan 0-0 5079
Nissan Urvan 0-0 5080
Nissan Urvan 0-0 5081
Nissan Van 1986-1989 5082
Nissan Vanette 0-0 5083
Nissan Vanette Europe 0-0 5084
Nissan Vector 1987-1991 5085
Nissan Violet 1973-1977 5086
Nissan Violet 1973-1977 5087
Nissan Violet 1978-1982 5088
Nissan Violet 1978-1982 5089
Nissan Xterra 1998-2003 5090
Nissan Xterra 2004-0 5091
Nissan X-Trail 1998-2000 5092
Nissan X-Trail 2001-0 5093
Nissan X-Trail 2001-0 5094
Nissan 100NX 1991-1999 4757
Nissan 1200 1970-1973 4758
Nissan 1200 1970-1973 4759
Nissan 120Y 1973-1978 4760
Nissan 120Y 1973-1978 4761
Nissan 120Y 1978-1982 4762
Nissan 120Y 1978-1982 4763
Nissan 140J 1978-1982 4764
Nissan 140J 1978-1982 4765

Images: How to use SEC-E9 key machine for Nissan key decoding and cutting


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes


			2006 Nissan Altima: How to Cut keys and Program remotes

Credits to the Spanish user for his contribution.

2006 Nissan Altima Key Cutting by SEC-E9 & Remote Programming with Consult 3 Plus

Rating
( No ratings yet )
Like this post? Please share to your friends:
