JMD Handy Baby 2 Remote Key Renew Wiring Diagram

As titled, here’s remote/smart key renew wiring diagram to JMD Handy Baby II 2nd generation key copy machine.

If you find the chip list is less than other key copiers (VVDI Key Tool, KD-X2 etc),  don’t worry,  keep an eye out for it with new updates.

Handy baby 2 renew cable and pinout

AUDI

KEY INFORMATION              CHIP                  NOTE

8T0959754   433MHz             PCF7945             233.423.111-02

8T0959754A  315MHz           PCF7945             233.423.111-02

8T0959754D 868MHz          PCF7945             233.423.111-02

8T0959754F 433MHz           PCF7945            233.423.111-02

4G0959754G 315MHz           PCF7945             233.423.111-05.06

4G0959754K 868MHz          PCF7945            233.423.111-05.06

4H0959754G 315MHz          PCF7945             233.423.111-05.06

4H0959754K 868MHz          PCF7945             233.423.111-05.06

8T0959754 433MHz             PCF7945             233.423.111-05.06

8T0959754D 868MHz         PCF7945            233.423.111-05.06

4H0959754DA 433MHz       PCF7945         233.423.111-01.02

4H0959754DB 315MHz         PCF7945            233.423.111-01.02

4H0959754DD 868MHz        PCF7945         233.423.111-01.02

DIAGRAM

BMW

BMW E-SERIES Remote Key

INFO 芯片类型/CHIP 备注/NOTE

5WK49125 868MHz PCF7945 CAS3

5WK49127 315MHz PCF7945 CAS3

INFO

BMW E-SERIES smart key

5WK49145 868MHz PCF7953 CAS3

5WK49147 315MHz PCF7953 CAS3

BMW F-SERIES Smart Card

5WK49661    868MHz     PCF7953     Contiental

5WK49663    315MHz      PCF7953     Contiental

5WK49662    433MHz     PCF7953     Contiental

BMW F-SERIES Smart Card

HUF5561    868MHz    PCF7953   Huf

HUF5562    315MHz     PCF7953   Huf

BMW F-SERIES Smart Key

HUF5563   868MHz   PCF7953   Huf

HUF5767    315MHz    PCF7953   Huf

BUICK/CHEVROLET

PCB5 4BTN   315MHz    PCF7952
PCB5 5BTN   315MHz    PCF7952
PCB5 5BTN   433MHz    PCF7952
PCB5 4BTN   433MHz    PCF7952
PCB5 5BTN   433MHz    PCF7952

CHRYSLER/JEEP/DODGE

IYZ-C01C PCF7941

IYZ-C01C smart key PCF7945

OHT692713AA PCF7941

OHT692427AA PCF7941

M3N5WY783X TYPE1 PCF7941

M3N5WY783X TYPE2 PCF7941

M3N5WY72XX PCF7941

K0B0T04A PCF7961

HYUNDAI/KIA

SVI-HMFNA04 PCF7952
SVI-HMFKR04 PCF7952
SVI-HMFEU04 PCF7952

MP13L-12 PCF7953

SVI-CMFEU03 PCF7952

SVI-CMFCH02 PCF7952

SVI-DMFGE03   PCF7953   2013DJ5952

SVI-DMFGE04 PCF7953
SVI-DMFNA04 PCF7953

SVI-KHFGE04 PCF7953
SVI-KHFNA433 PCF7953

LAND ROVER

YWX000061   434MHz   PCF7941    Visteon
YWX000071    315MHz   PCF7941    Visteon

5EOU40247   434MHz   PCF7953

MITSUBISHI

GD8-644M 434MHz PCF7953

NISSAN

A2C53405173   HITAG3   PCF7953  433MHz
A2C53188764   HITAG3   PCF7953  315MHz

A2C53405175 HITAG3 PCF7953

A2C32801600 HITAG AES PCF7953
A2C32800800 HITAG AES PCF7953

A2C53297341 PCF7952 HITAG2

MAZDA

JX331BB1002A 2BTN PCF7945
JX331BB1002A 3BTN PCF7945

PORSCHE

7PP59753BS   434MHz    PCF7953
7PP59753BN   434MHz   PCF7953
7PP59753BM   315MHz   PCF7953
7PP59753BQ   315MHz    PCF7953
7PP59753AJ    434MHz   PCF7953

VOLVO

5WK49266 900MHz PCF7953
5WK49269 433MHz PCF7953

PEUGEOT/CITROEN

E33C1002 PCF7941
E25C1009 PCF7941

E28CI01B PCF7941

21676652 PCF7941

RENAULT

285971998R 433MHz PCF7953
285974100 433MHz PCF7953 HITAG AES

285975779R 433MHz PCF7952

AK010008 433MHz PCF7961

805673071R 433MHz PCF7961

285970036R 433MHz PCF7941 HITAG2

GREAR WALL

285979045R 433MHz

Keep updating…
